系列 | Ordering No 下单型号 | ESD | Package Type | Configuration | MOSFET Type | VDS (V) | VGS (V) | Vth typ. (V) | RDS(ON) (mΩ) typ. at VGS= | ID (A) | ||
10V | 4.5V | 2.5V | ||||||||||
SJ | XR650SJ520 | - | TO252-3L | Singel | N | 650 | ±30 | 3 | 550 | - | - | 8 |
XR650SJ24T | - | TO252-3L | Singel | N | 650 | ±30 | 3 | 190 | - | - | 20 | |
XR650SJ16T | - | TO252-3L | Singel | N | 650 | ±30 | 3 | 160 | - | - | 20 | |
XR65R500 | - | TO252-3L | Singel | N | 650 | ±30 | 3 | 500 | - | - | 8 | |
XR65R380 | - | TO252-3L | Singel | N | 650 | ±30 | 3 | 380 | - | - | 11 | |
XR65R380T | - | TO220AB | Singel | N | 650 | ±30 | 3 | 380 | - | - | 11 | |
XR65R380FT | - | TO220F | Singel | N | 650 | ±30 | 3 | 380 | - | - | 11 | |
XR65R250T | - | TO220AB | Singel | N | 650 | ±30 | 3 | 250 | - | - | 13 | |
XR65R250FT | - | TO220F | Singel | N | 650 | ±30 | 3 | 250 | - | - | 13 | |
XR65R110T | - | TO220AB | Singel | N | 650 | ±30 | 3 | 110 | - | - | 24 | |
XR65R110FT | - | TO220F | Singel | N | 650 | ±30 | 3 | 110 | - | - | 24 | |
XR65R90FRH | - | TO247 | Singel | N | 650 | ±30 | 3 | 90 | - | - | 31 | |
XR65R75FRH | - | TO247 | Singel | N | 650 | ±30 | 3 | 75 | - | - | 43 | |
